01
Study the full demand range
Compare both low and high operating demand with the variable-speed model's listed 436 CFM at 125 PSI. A single peak reading does not describe the complete load profile.
OMORFO ROTARY SCREW COMPRESSOR
Omorfo OM100V 100 HP rotary screw air compressor
The Omorfo OM100V is a variable-speed direct-drive rotary screw air compressor rated at 100 HP and 436 CFM at 125 PSI. It is listed for 230/460 V, 3-phase, 60 Hz service, with a 75 dB sound rating, 4,321 lb weight, and 2-inch air outlet.
OM100V model detail
Variable-speed direct drive
- Motor
- 100 HP
- Rated airflow
- 436 CFM
- Rated pressure
- 125 PSI
- Sound rating
- 75 dB
MODEL OVERVIEW
Evaluate the OM100V against measured demand.
The OM100V should be evaluated from a logged or otherwise defensible facility demand profile. Its variable-speed direct-drive configuration is a relevant control and drive detail, but the decision still begins with required flow across the operating range, the 125 PSI rating, and pressure delivered to production—not the 100 HP nameplate by itself.
At a listed 4,321 lb with a 2-inch outlet, this model also requires early coordination around delivery, handling, equipment placement, and the connection to the plant air system. Electrical service, ventilation, sound, air treatment, drainage, controls, and service access need to be resolved for the actual site and ordered configuration.
OM100V published specifications
- Model
- OM100V
- Motor power
- 100 HP
- Rated pressure
- 125 PSI
- Rated airflow
- 436 CFM
- Electrical supply
- 230/460 V, 3-phase, 60 Hz
- Published sound rating
- 75 dB
- Drive and control
- Variable-speed direct drive
- Listed weight
- 4,321 lb
- Air outlet
- 2-inch
Specification notice: Published values are based on current manufacturer information. Specifications and configurations can change and must be confirmed with Bluegrass Air Power and Omorfo for the unit being quoted or ordered.
Review Omorfo's current rotary compressor information (opens in a new tab)APPLICATION FIT
Where the OM100V enters the selection process
Published output establishes a comparison point. The application, demand pattern, site, and complete air-system design determine whether this specific model belongs in a final quote.
02
Plan for 4,321 lb
Coordinate delivery access, handling, placement, and the supporting installation with qualified project participants using the manufacturer-listed equipment weight.
03
Design around the 2-inch outlet
Review how the listed outlet connects to the plant header and how pipe sizing, routing, treatment equipment, and pressure loss affect delivered air.
04
Verify utilities and location
Confirm the ordered 230/460 V, 3-phase, 60 Hz electrical configuration and evaluate the published 75 dB rating, ventilation, and service clearances for the actual room.
BEFORE A QUOTE
Questions to answer before choosing the OM100V
Bring these answers to the equipment conversation. Clear operating requirements are more useful than choosing from horsepower alone.
Discuss the OM100V- How does facility air demand vary by shift, production state, and simultaneous equipment use?
- Does 436 CFM at 125 PSI cover the documented operating range while maintaining the required pressure at each critical process?
- How will the variable-speed compressor interact with storage, controls, and any other compressors in the system?
- Can the delivery route, handling plan, equipment location, and supporting installation accommodate the listed 4,321 lb weight?
- How will the 2-inch outlet connect to the plant header, and what pressure loss is expected through piping and treatment components?
- Which listed voltage configuration will be supplied, and has the 3-phase, 60 Hz electrical scope been confirmed?
- What room placement and sound planning are appropriate for the published 75 dB rating?
- What ventilation, drying, filtration, condensate, and maintenance-access requirements must be included in the project scope?
NEXT STEPS
Plan the compressor as part of the full air system.
Selection, site requirements, air treatment, and ordered configuration should be evaluated together. These resources help turn the model rating into a better-scoped project discussion.
Size the load
Compressor sizing guide
Organize CFM, PSI, runtime, power, and site details before comparing equipment.
Read the guide →Prepare the request
Application quote
Share demand, pressure, electrical, site, and timeline details for a focused equipment and pricing conversation.
Request a quote →Compare the category
Rotary screw guide
Review duty cycle, controls, site conditions, air quality, and lifecycle questions.
Compare decisions →Local supplier
Henderson, Kentucky
Learn how Bluegrass Air Power approaches industrial compressor selection across the Ohio Valley.
View local options →RELATED MODELS
Compare other listed Omorfo compressors.
HENDERSON, KENTUCKY • OHIO VALLEY
Get a focused OM100V quote.
Share your required CFM and PSI, operating schedule, electrical service, air-quality needs, and installation constraints with Bluegrass Air Power in Henderson.
